| Vehicle technical parameters | |||
| Vehicle name: | CLW5251ZYSD5 compression garbage truck | Announcement batch: | 289 |
| Product trademark | Chengliwei brand | Product ID | |
| Vehicle model: | CLW5251ZYSD5 | Catalog number: | (17)74 |
| Inspection-free: | release date: | 20161028 | |
| total mass | 25000(Kg) | Volume: | |
| Rated contained mass | 8505(Kg) | curb weight | 16300(Kg) |
| Dimensions | 10480,10280×2500×3250(mm) | Cargo compartment size | ××(mm) |
| Rated passenger capacity | (people) | Total mass of quasi-trailer | (kg) |
| Cab: | Front seat passenger: | 3(people) | |
| Anti-lock braking system: | have | Load capacity utilization factor | |
| Fuel type: | diesel fuel | Emission Standards: | GB3847-2005, GB17691-2005 National V |
| Approach/departure angle: | 18/12(°) | Front suspension/rear suspension: | 1480/3300,1480/3100,1500/3300,1500/3100(mm) |
| Number of axes: | 3 | Wheelbase: | 4350+1350,5350+1350,5700+1350,3800+1350(mm) |
| Number of tires: | 10 | Tire specifications: | 11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR |
| Front wheelbase (mm): | 2040 | Rear wheelbase (mm): | 1860/1860 |
| Axle load: | 7000/18000 (two-axis group) | Maximum speed: | 90(km/h) |
| other | 1. The selected wheelbase (mm) of this car is: 4350+1350. 2. This car has five optional flip styles, A: Triangular bucket device, B: Bucket device, C: Swing arm device, D: Large floor bucket Device , E: No rear flip device. When ABCD is selected, the corresponding relationship between the car's front overhang (mm) / vehicle length (mm) / rear overhang (mm) is: 1480/10480/3300, 1500/10500/3300; when E is selected, the car's The corresponding relationship between front overhang (mm)/vehicle length (mm)/rear overhang (mm) is: 1480/10280/3100, 1500/10300/3100. 3. Protection material: Q235 carbon steel , connection method: left and right side protection It is connected to the sub-frame by welding, and the rear protection is replaced by a special device for exemption. 4. ABS manufacturer: Dongkeknuoer Commercial Vehicle Braking System (Shiyan) Co., Ltd .; Model: 3631010-C2000. 5. Vehicle color, text spraying and local details can be changed. 6. The corresponding relationship between engine and fuel consumption value is (L/100km): ISD245 50/35.4, ISD270 50/35.9 | ||
| Chassis DFL1250A13 technical parameters | |||
| Chassis model | DFL1250A13 | Chassis company: | Dongfeng Commercial Vehicle Co., Ltd. |
| Number of tires | 10 | Number of spring leaves: | 8/9,8/10,9/10 |
| Tire specifications: | 11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR | Steering Type: | steering wheel |
| Front track: | 2040 | Rear wheelbase: | 1860/1860,1880/1880 |
| Chassis emission standards: | GB3847-2005, GB17691-2005 National V | ||
| Fuel type: | diesel fuel | batch: | 310 |
| engine model | Engine manufacturer | Displacement (ml) | Power(kw) |
| ISD245-50 ISD270-50 DDi75S350-50 DDi75S245-50 DDi75S292-50 |
Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Commercial Vehicle Co., Ltd. Dongfeng Commercial Vehicle Co., Ltd. Dongfeng Commercial Vehicle Co., Ltd. |
6700 6700 7530 7530 7530 |
180 198 257 180 215 |
| Logo company: | Changzhou Huarisheng Reflective Material Co., Ltd., Changzhou Huawei Reflective Material Co., Ltd. | Vin vehicle identification code: | LGAX4C44 × × × × × × × × × LGAX4C45 × × × × × × × × × LGAX4C43 × × × × × × × × |
