| Main technical data of Dongfeng Tianlong 8x4 refrigerated truck meeting China VI emission standards | |||
| Product Name | Dongfeng Tianlong 8x4 refrigerated truck | External dimensions (mm) | 12000×2600×3990 |
| Vehicle Model | DFH5310XLCDX1 | Cargo box dimensions (mm) | 9500×2440×2450,2500 |
| Front passenger | 2,3 | Environmental protection/tax exemption | yes |
| Total mass (kg) | 31000 | Approach/departure angle (°) | 13/10 |
| Rated weight (kg) | 17940, 17875, 16840, 16775 | Front overhang/rear overhang (mm) | 1480/2775, 1480/2575 |
| Curb weight (kg) | 12930,14030 | Maximum speed (km/h) | 89 |
| Emission standards | GB3847-2005, GB17691-2018 Country VI | ||
| National VI Dongfeng Tianlong 8x4 Refrigerated Truck Chassis Parameters | |||
| Chassis Model | DFH1310D1 | Types of fuel | diesel fuel |
| Number of axes | 4 | Front track width (mm) | 2010/2010,2040/2040 |
| Wheelbase (mm) | 1995+4400+1350, 1995+4600+1350 | Rear track width (mm) | 1860/1860, 1880/1880 |
| Number of tires | 12 | Tire specifications | 11.00R20 18PR,295/80R22.5 18PR |
| Engine parameters of Dongfeng Tianlong 8x4 refrigerated truck meeting China VI emission standards | |||
| Engine Model | Engine manufacturers | Displacement (ml) | Power (kW) |
|
L9NS6B360 L9NS6B400 |
Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. |
8900 8900 |
265 294 |
