| Key Technical Data of Foton Aoling Express Refrigerated Truck ( National VI Emission Standard) | |||
| Product Name | Foton Aoling Express Refrigerated Truck | External dimensions (mm) | 5995×2160×3065 |
| Vehicle Model | BJ5045XLC8JDA-AB1 | Cargo box dimensions (mm) | 4085×2000×1900 |
| Front passenger | 2 | Environmental protection/tax exemption | yes |
| Total mass (kg) | 4495 | Approach/departure angle (°) | 19/16 |
| Rated weight (kg) | 1100 | Front overhang/rear overhang (mm) | 1110/1525 |
| Curb weight (kg) | 3200 | Maximum speed (km/h) | 95 |
| Emission standards | GB3847-2005, GB17691-2018 Country VI | ||
| National VI emission standard Foton Aoling Express refrigerated truck chassis parameters | |||
| Chassis Model | BJ1045V9JDA-AB1 | Types of fuel | diesel fuel |
| Number of axes | 2 | Front track width (mm) | 1590, 1720 |
| Wheelbase (mm) | 2700, 2950, 3308 | Rear track width (mm) | 1485,1590 |
| Number of tires | 6 | Tire specifications | 7.00R16LT 8PR, 7.50R16LT 6PR |
| National VI emission standard Foton Aoling Express refrigerated truck engine parameters | |||
| Engine Model | Engine manufacturers | Displacement (ml) | Power (kW) |
|
Q28-130E60 4J28TC6 F2.8NS6B131 |
Anhui Quanchai Power Co., Ltd. Beiqi Foton Motor Co., Ltd. Beijing Foton Cummins Engine Co., Ltd. |
2800 2771 2780 |
96 88 96 |
